Amprius SA03 Pouch Cell 11600mAh High Energy Density Battery for Drone

Amprius SA03 Pouch Cell 11600mAh High Energy Density Battery for Drone

For bulk orders, datasheets or custom pack projects, click Request a Quote or email jerryli@shlizone.com with model, quantity and application.

$38.00 USD
$38.00 USD
Sale Sold out
Shipping calculated at checkout.
Request a Quote

Amprius SA03 is a high energy density rechargeable lithium-ion polymer pouch cell designed for UAV, drone, aerospace and aviation battery pack applications. With 11600mAh nominal capacity, 3.40V nominal voltage and approximately 39.4Wh nominal energy, SA03 is suitable for long-endurance drone platforms and lightweight battery pack projects.

Key Features

  • Original Amprius SA03 lithium-ion polymer pouch cell
  • 11600mAh nominal capacity at 0.2C discharge
  • 3.40V nominal voltage and 4.2V max charge voltage
  • Approx. 39.4Wh nominal energy
  • Approx. 383Wh/kg gravimetric energy density, calculated from nominal energy and cell weight
  • Supports 1C max discharge, 2C discharge for 5 minutes and 3C discharge for 2 minutes
  • Designed for UAV, drone, aerospace and aviation battery pack applications

Specifications

Manufacturer Amprius
Model SA03
Battery Type Lithium-ion Polymer Pouch Cell
Nominal Capacity 11600mAh
Nominal Voltage 3.40V
Charge Cut-off Voltage 4.2V max
Discharge Cut-off Voltage 2.5V min
Standard Charge 0.2C CC to 4.2V, then CV to 0.02C cut-off
Standard Discharge 0.2C discharge to 2.5V cut-off
Max Charge Current 1/3C
Max Discharge Current 1C
Pulse Discharge 2C for 5min / 3C for 2min
Charge Temperature 10°C to 55°C
Discharge Temperature -20°C to 55°C
Weight 103.0g +/- 1.0g
Dimensions 6.32mm x 52.5mm x 139.5mm
Initial Impedance <=20mΩ

Application

The Amprius SA03 cell is recommended for professional battery pack builders, UAV manufacturers, drone developers, aerospace-related projects and aviation battery systems where compact size, low weight and high usable energy are important.

Safety Notice

This cell should only be used within manufacturer-listed specifications and with proper protection circuitry in a battery pack. Do not overcharge, over-discharge, short circuit, puncture, crush, solder manually or expose the cell to fire, liquid or high temperature. Battery pack design should include over-charge, over-discharge, over-current, over-heat and short-circuit protection.

Amprius_SA03_Product_Specification

View full details

OUR WAREHOUSE

Our warehouse keeps long-term stock of Molicel and other battery cells. For in-stock items, orders are usually processed within 2 to 3 business days. Contact us for current availability, datasheets and wholesale pricing.

  • FAQ

    WHO WE ARE?

    SHLIZONE supplies lithium-ion battery cells and battery pack accessories for professional battery pack builders, UAV projects, robotics, power tools and custom battery pack applications.

    For each product, please refer to the listed model number, datasheet and specifications. Brand names are used only to identify the battery cell model and manufacturer.

    For bulk orders, datasheets, matching cells or project sourcing, please contact us with the model, quantity, destination country and application.

  • .

  • For your safety please read the following precautions

    WARNING:

    The user must have appropriate understanding of lithium ion batteries before purchase. Use caution when working with and using lithium ion batteries as they are very sensitive to charging characteristics and may explode, burn, or cause a fire if misused or mishandled. Always charge in or on a fire-proof surface. Never leave batteries charging unattended. Buyer is responsible for any damage or injury caused by misuse or mishandling lithium ion batteries and chargers. No express or implied guarantee of compatibility with any device can be made. Charge only with a smart charger designed for this specific type of lithium ion battery. Do not mix and match old and new, used and unused batteries.

    ▲DO NOT USE WITH E-CIGARETTE, VAPORIZER, OR SIMILAR DEVICE

    ▲MISUSING OR MISHANDLING LITHIUM ION BATTERIES CAN POSE A SERIOUS RISK OF PERSONAL INJURY, PROPERTY DAMAGE, OR DEATH

    ▲BATTERIES MAY EXPLODE, BURN, OR CAUSE A FIRE IF MISUSED OR MISHANDLED

    ▲ONLY USE WITH PROPER CIRCUITRY IN A PROTECTED BATTERY PACK

    ▲ONLY USE WITHIN MANUFACTURER LISTED SPECIFICATIONS

    ▲DO NOT STORE LOOSE BATTERY IN A POCKET, PURSE ETC. - ALWAYS USE A PROTECTIVE CASE OR BOX

    ▲KEEP AWAY from metal objects to prevent short circuiting

    ▲DO NOT short circuit

    ▲DO NOT use if wrapper or insulator is damaged or torn

    ▲DO NOT use if damaged in any way

    ▲DO NOT overcharge or over-discharge

    ▲DO NOT modify, disassemble, puncture, cut, crush, or incinerate

    ▲DO NOT expose to liquids or high temperatures

    ▲DO NOT solder, spot weld only

    ▲User must be familiar with handling lithium ion batteries before purchase

    ▲Usage of batteries is AT YOUR OWN RISK

    ▲ALWAYS charge in or on a fire-proof surface and never leave charging batteries unattended

    ▲RESELLERS MUST FORWARD ALL WARNINGS TO ALL CUSTOMERS FOR THEIR REFERENCE AND SAFETY

    VAPE / E-CIG BATTERY WARNING

    This battery is manufactured and sold for the intended use of system integrations with proper protection circuitry or battery packs with a BMS (battery management system) or PCB (circuit board/module). This battery is neither designed nor intended to be used with an e-cig, vape, or similar device. USAGE OF THIS BATTERY IS AT YOUR OWN RISK!

    Local regulations and laws pertaining to the recycling and disposal of lithium ion batteries vary so please consult your local jurisdiction regarding appropriate disposal. Many retail stores offer free recycling of rechargeable batteries.
